DAB Divertron Pumps 230v
Divertron 1000
In stock
- Established 1975
- Trusted by thousands of customers
Now supplied as the Divertron 650
Order this listing — we’ll send the new energy-efficient Divertron 650 as a direct replacement.
The DAB Divertron 1000 has been replaced by the new green-bodied Divertron 650. Same pipe connection, comparable performance, more efficient motor for lower running costs.
- Order this listing — we’ll supply the new Divertron 650
- Same 1″ pipe connection — drops into existing pipework
- More efficient motor for lower running costs
- Same integrated electronics & dry-run protection
- Float-switch version (650A) also available
DISPATCHED 3–4 WORKING DAYS
NEXT-DAY AVAILABLE
More about this product
Now supplied as the DAB Divertron 650
The DAB Divertron 1000 has been replaced by the new energy-efficient Divertron 650 as part of DAB’s updated (green-bodied) Divertron range. If you order this product, we’ll supply the new Divertron 650 as a direct replacement — same 1″ pipe connection, comparable performance, more efficient motor for lower running costs.
The DAB Divertron 1000 was a submersible multi-impeller booster pump with fully integrated electronics — used for clean water pressurisation, garden irrigation and rainwater reuse. It was designed to drop into a well, tank, cistern or borehole chamber and provide automatic on-demand pressure to taps, sprinklers and non-potable household feeds.
It has now been discontinued and replaced by the new green-bodied Divertron 650, which uses a more efficient motor for the same duty. The information below covers the original 1000 for reference; orders against this listing will be fulfilled with the new 650 model.
What the 1000 was used for
Garden irrigation from rainwater tanks, sprinkler and drip systems, outside taps and pressure washers fed from a cistern or well. Single-storey rainwater reuse for non-potable household duties. Pressure boosting from private water sources where mains pressure was unavailable or insufficient.
All these applications are covered by the new 650 with the same suitability — and lower running costs.
Original Divertron 1000 specifications
| Pressure range | 3.6 – 0.8 bar |
| Flow range | 0.5 – 5.0 m³/h |
| Motor (P2) | 0.65 kW |
| Power supply | 230 V, 50 Hz, single phase |
| Nominal current | 3.8 A |
| Discharge connection | 1″ threaded |
| Status | Discontinued — replaced by Divertron 650 |
Why the new Divertron 650 is the right replacement
If you have an existing Divertron 1000 installed and need a like-for-like replacement, the new 650 is the direct successor. It uses the same pipe connection, fits the same installation envelope, and covers the same range of applications.
- Same pipe connection — 1″ threaded discharge, drops into existing pipework
- Comparable performance — similar head, flow and pressure envelope for typical duties
- Lower energy demand — more efficient motor for reduced running costs over its lifetime
- Same integrated electronics — pressure switch, flow sensor and dry-run protection built in
- Float-switch version available — Divertron 650A for tanks that may run dry
Need help choosing?
If you’re unsure whether the Divertron 650 is the right fit for your existing setup — or if you’d benefit from the float-switch 650A — get in touch. We’ll talk through your installation and confirm the right model before you order.
Frequently asked questions
Will the new 650 fit where my existing 1000 sat?
Yes, in the vast majority of installations. Both pumps share the same 1″ threaded discharge and similar physical envelope, so existing pipework, brackets and supports will accept the new model. If your installation is unusual or tightly fitted, send us a couple of photos and measurements and we’ll confirm.
Is performance the same?
For most domestic and garden duties — single-storey feeds, irrigation, outside taps, rainwater reuse — the new 650 covers the same applications as the 1000. The 650 has a 0.56 kW motor versus 0.65 kW for the 1000, but uses a more efficient design to deliver comparable real-world performance with lower energy use. If your installation pushed the limits of the 1000, the higher-pressure Divertron 900 may be a better choice — get in touch and we’ll advise.
Can I still get spare parts for the 1000?
Some service parts may still be available through DAB. Get in touch with the part you need and we’ll check current availability — but for most enquiries, replacement with the new 650 is more cost-effective than repair.
What if I need the float-switch version?
The new range includes the Divertron 650A with an integrated float switch, suited to shallow rainwater tanks or any source that may run dry. Order this listing if you want a float-switch replacement for your old 1000 and we’ll supply the 650A in place of the standard 650.
How quickly can I get one?
In stock for dispatch within 3–4 working days on standard delivery. Next working day delivery is available for orders placed before 12 noon.
-
Tech sheet PDFDownload
-
data sheet PDFDownload
-
manual PDFDownload
