Mikrofill 3 Pro Pressurisation unit 72846
- Established 1975
- Trusted by thousands of customers
The Mikrofill 3 PRO is a fully automatic sealed-system filling device for the water management of domestic and commercial heating and cooling systems. Compact, efficient and easy to install and commission, it uses smart logic alongside pressure and flow sensors to detect and alert on system issues early, while requiring minimal maintenance.
WRAS-approved with integral Fluid Category 4 backflow prevention (approval no. 2307805), it delivers up to 8.7 bar cold fill pressure, a full-colour 3.95″ display, leak detection, volume logging and MODBUS RTU with four customisable BMS outputs. Wall-mountable and compact at just 250mm wide. Standard 2-year warranty, extended to 4 years when purchased with a vessel package.
- WRAS-approved — Fluid Category 4 backflow prevention (approval no. 2307805); suitable for sealed heating and chilled water systems
- Smart fault logic & leak detection — early detection and alerts for system issues, with minimal maintenance
- Full-colour 3.95″ LCD — comprehensive electronic pressure management and on-screen service reminders
- Accurate flow monitoring & volume logging — live flow readings to ±3%; logs up to 100 time/date-stamped changes and faults
- MODBUS RTU + 4 customisable BMS outputs — full building management integration
- Standard 2-year warranty — extended to 4 years when purchased with a vessel package
More about this product
The Mikrofill 3 PRO is a fully automatic sealed-system filling device for the water management of domestic and commercial heating and cooling systems. The unit is compact, efficient, and easy to install and commission. Using smart logic alongside pressure and flow sensors, it provides early detection and alerts for system issues, and is designed to require minimal maintenance.
WRAS-approved with integral Fluid Category 4 backflow prevention (approval no. 2307805), it offers up to 8.7 bar cold fill pressure, a full-colour 3.95″ display, leak detection, comprehensive volume logging, and MODBUS RTU with four customisable BMS outputs for full building management integration.
Key features
- WRAS-approved — Fluid Risk Category 4 backflow prevention (WRAS approval no. 2307805)
- 8.7 bar max cold fill pressure — suitable for systems of significant height
- Compact, wall-mountable design — just 250mm wide; backplate supplied
- Full-colour 3.95″ LCD display with comprehensive electronic pressure management
- Accurate flow rate monitoring & volume logging — live readings to ±3%
- Leak detection & smart fault logic for rapid fault diagnosis
- MODBUS RTU + 4 customisable BMS outputs
- Large memory capacity — records up to 100 parameter changes and fault conditions combined, all time and date stamped
- Easy to install and set up
- Standard 2-year warranty — extended 4-year warranty when purchased with a vessel package
Smart control & monitoring
- Colour backlit LCD screen with pressure setting resolution of ±0.1 bar
- Low inlet pressure cut-out (0.3 bar) and high/low pressure fault indication
- User password access and hand mode for manual operation
- Flood protection (run-time limiter) and user-set on-screen service reminder
- Customisable volt-free contacts and usage monitor with fill volume, logs and counters
- Live, in-situ testing for service and repair
Applications
- Maintaining system pressure in large domestic and commercial sealed heating systems
- Maintaining system pressure in chilled water systems, refrigeration units and industrial cooling systems
Operating specifications
| Max inlet pressure | 9 bar |
| Max cold fill pressure | 8.7 bar |
| Max operating pressure | 9 bar |
| Max flow rate | 12 l/min |
Dimensions & connections
| Height (to bottom of connections, without hoses) | 290 mm |
| Height (to bottom of tundish) | 386 mm |
| Width | 250 mm |
| Depth | 155 mm |
| Weight (without hoses) | 5.3 kg |
| Inlet / System connection | 15 mm compression |
| Drain connection | 22 mm compression |
| Wall attachment | Backplate supplied (fixings not included) |
| Clearances (L / R / top / front) | 100 / 170 / 100 / 750 mm |
Electrical & environmental
| Supply voltage | 230 V / 1 ph / 50 Hz |
| Fuse rating | 3 A |
| BMS relays (max load) | 5 A |
| Ambient temperature range | 5 – 45°C |
| Inlet water temperature range | 5 – 23°C |
| System water temperature range | 5 – 85°C |
| Maximum relative humidity | 70% (non-condensing) |
| IP rating | IP55 |
| Fluid protection | WRAS Category 4 / Kiwa Regulation 4 |
Warranty & accessories
- Standard warranty: 2 years
- With vessel package: 4 years
- Supplied with: 2× braided hoses with integrated isolation valve
-
Data Sheet PDFDownload
