Pedrollo TOP FLOOR Low Suction Submersible Drainage Pump
Pedrollo TOP 3-FLOOR Submersible Drainage Pump Single Phase – 2305463
- Established 1975
- Trusted by thousands of customers
The Pedrollo TOP 3-FLOOR is a submersible drainage pump that drains to 2 mm. It has a 0.55 kW (0.75 HP) motor on a 230 V single-phase supply. It delivers up to 170 l/min and 10.4 m head.
Pedrollo design the TOP-FLOOR to remove water down to 2 mm from the floor. It suits emergency drainage of small flooded areas at home.
More about this product
Product overview
The Pedrollo TOP 3-FLOOR is a submersible drainage pump with a 0.55 kW (0.75 HP) motor. It runs on a 230 V single-phase supply. It covers 20 to 170 l/min, with a working head of 9.8 m down to 2.6 m.
Pedrollo design the TOP-FLOOR to remove clear water down to 2 mm from the floor. It suits emergency household use in small flooded areas, and anywhere you need maximum drainage. A float switch is available on request.
Key features
Typical applications
Technical specifications
| Brand / Series | Pedrollo — TOP-FLOOR |
| Model | TOP 3-FLOOR |
| Pedrollo code | 2305463 |
| Supply | 230 V single-phase |
| Motor power (P2) | 0.55 kW / 0.75 HP |
| Motor | 230 V single-phase motor with thermal protection in the winding |
| Flow range | 20–170 l/min |
| Head range | 9.8–2.6 m |
| Current | 3.1 A at 230 V |
| Maximum head | 10.4 m |
| Pump body, suction filter, diffuser | Technopolymer |
| Impeller | Noryl™ |
| Suction cover, motor sleeve, motor cover | AISI 304 stainless steel |
| Motor shaft | AISI 431 stainless steel |
| Mechanical seal | STA-12R, Ø 12 mm, ceramic / graphite / NBR, with sealing ring and oil chamber |
| Port | 1¼″ |
| Hose connector | Ø 35 mm |
| Float switch | Not included; available on request |
| Power cable | 5 m (H07 RN-F) with Schuko plug; 10 m on request |
| Solids passage | Up to Ø 2 mm |
| Draining capability | Down to 2 mm from the floor |
| Maximum depth | 3 m below water level (with an appropriately sized power cable) |
| Liquid temperature | Up to +40 °C; up to +90 °C in short bursts (3 minutes max) for intermittent service |
| Insulation / protection | Class F / IP X8, continuous duty S1 |
| Liquid | Clear water |
| Height | 287 mm |
| Weight | 6.6 kg |
| Available on request | Float switch; mechanical seal options; 10 m power cable; other voltages and 60 Hz |
TOP-FLOOR range
| Model | Code | Supply | Power | Flow | Head |
|---|---|---|---|---|---|
| TOP 1-FLOOR | 2300123 | Single Phase | 0.25 kW / 0.33 HP | 20–120 l/min | 6–2 m |
| TOP 2-FLOOR | 2300133 | Single Phase | 0.37 kW / 0.5 HP | 20–150 l/min | 8–2.4 m |
| TOP 3-FLOOR | 2305463 | Single Phase | 0.55 kW / 0.75 HP | 20–170 l/min | 9.8–2.6 m |
Head shown as the working range from minimum to maximum flow. Performance to Pedrollo 50 Hz data.
Frequently asked questions
How low does it drain?
Down to 2 mm from the floor.
Does it have a float switch?
No. Pedrollo supply a float switch version on request.
How long is the cable?
5 metres with a Schuko plug. A 10 m cable is available on request.
-
Data Sheet PDFDownload
Standard delivery:
Standard delivery is free on most orders. Some items may incur a delivery charge depending on weight, size or value. Any applicable charge will be displayed at checkout.
Deliveries will typically be made between 7am and 6pm, Monday to Friday (excluding public holidays).
Next day delivery:
Next working day delivery is available for a £16.50 + VAT delivery charge.
Orders must be placed before 12 noon to qualify for next working day delivery. Orders placed after 12 noon on Thursday but before noon on Friday will be delivered the following Monday. Orders placed after 12 noon on Friday will be delivered on Tuesday.
Pallet/Large/Difficult items:
Some large, heavy or difficult to transport items may incur an additional delivery charge. Please contact us for a delivery quote before ordering.
Related products
DOMO series, stainless steel electric pumps, are available with twin-channel or vortex impeller (DOMO VX). Designed to handle suspended solids up to 50mm in diameter…
The Hippo 2 offers high performance at a low price, ideal for home and garden use this great submersible water pump will pump with 3,2mm…
The Clarke PSD1A stainless steel pump designed to clear water from ponds and pools. Suitable for operating waterfalls, fountains, irrigating gardens and draining cellars. Includes a…
The Clarke PSV1A water pump is designed particulary for heavy duty applications. This robust, powerful water pump is ideal for rapidly shifting both clean and…
The Clarke CSD3 multi-stage 4 impeller pump is for use with cold, clean water i.e. wells or rain water tanks and can pump up to…
The Clarke HSE pumps suitable for pump both dirty and clean water.
Frequently Asked Questions
Quick answers to common questions about the Pedrollo TOP 3-FLOOR Submersible Drainage Pump Single Phase – 2305463. For technical specifications, see the product details above; for sizing or installation advice, contact our team. If you have any other questions, we're happy to help.
What is a submersible pump?
A submersible pump is designed to operate fully submerged in the liquid it is moving. The motor is sealed inside the pump body and cooled by the surrounding water. Submersibles are used for drainage, sewage, septic tanks, deep wells and boreholes, and for raising water from sumps, cellars and floodwater. Many stocked at Anglian Pumping handle solids in suspension.
Can submersible pumps handle solids and sewage?
Yes – some submersibles are designed for clean water only, others handle solids up to 50 mm or full raw sewage. Anglian Pumping stocks ABS, BBC, Flygt and T-T Submersibles ranges that include vortex, single channel and grinder impellers for different solids handling requirements. Always match the pump to the maximum solid size and the type of effluent it will see.
When should I use a submersible pump instead of a surface pump?
Use a submersible when the water level is more than around 8 metres below the pump installation point – surface pumps cannot self-prime beyond that depth. Submersibles are also better when the liquid contains solids, when noise must be minimised, or when the pump needs to operate in confined spaces such as sumps and chambers where a surface pump would not fit.
