Pedrollo TOP 1-VORTEX Submersible Vortex Drainage Pump Single Phase - 2300142

Name: Pedrollo TOP 1-VORTEX Submersible Vortex Drainage Pump Single Phase - 2300142
Brand: Pedrollo
SKU: 2300142
Price: 309.6 GBP
Availability: InStock

Any questions? Message us on WhatsApp

Established 1975
Trusted by thousands of customers

The Pedrollo TOP 1-VORTEX is a vortex submersible drainage pump. It has a 0.25 kW (0.33 HP) motor on a 230 V single-phase supply. It delivers up to 140 l/min and 7 m head.

It passes solids up to Ø 25 mm and drains down to 25 mm.

140l/min

Max flow

Max head

0.25kW

0.33 HP

230V

Single Phase

Vortex impellerFloat switchSolids up to 25 mm5 m cableCode 2300142

Full Description

More about this product

Full Description

Product overview

The Pedrollo TOP 1-VORTEX is a vortex submersible drainage pump with a 0.25 kW (0.33 HP) motor. It runs on a 230 V single-phase supply. It covers 20 to 140 l/min, with a working head of 6.3 m down to 1.6 m.

Pedrollo design the TOP-VORTEX for domestic use. It drains dirty water, empties tanks and clears sumps and domestic drains. It handles suspended solids up to Ø 25 mm.

140l/min

Max flow

Max head

0.25kW

0.33 HP

230V

Single Phase

Key features

Vortex impeller

Technopolymer vortex impeller, passing solids up to Ø 25 mm.

Float switch

Included for automatic operation.

Stainless motor

AISI 304 motor sleeve and cover, AISI 431 shaft.

Oil chamber seal

Double shaft seal with an interposed oil chamber.

Typical applications

Dirty water

Domestic dirty water with solids up to Ø 25 mm.

Tanks and sumps

Emptying tanks and clearing sumps.

Domestic drains

Managing domestic drains.

Technical specifications

Brand / Series	Pedrollo — TOP-VORTEX
Model	TOP 1-VORTEX
Pedrollo code	2300142
Supply	230 V single-phase
Motor power (P2)	0.25 kW / 0.33 HP
Motor	230 V single-phase motor with thermal protection in the winding
Flow range	20–140 l/min
Head range	6.3–1.6 m
Current	1.5 A at 230 V
Maximum head	7 m
Pump body, suction filter, suction cover, diffuser	Technopolymer
Impeller	Vortex, technopolymer
Motor sleeve and cover	AISI 304 stainless steel
Motor shaft	AISI 431 stainless steel
Mechanical seal	STA-12R, Ø 12 mm, ceramic / graphite / NBR, with shaft seal and oil chamber
Port	1¼″
Hose connector	Ø 35 mm
Float switch	Float switch included
Power cable	5 m (H07 RN-F) with Schuko plug; 10 m on request
Solids passage	Up to Ø 25 mm
Draining capability	Down to 25 mm from the bottom
Maximum depth	3 m below water level (with an appropriately sized power cable)
Liquid temperature	Up to +40 °C; up to +90 °C in short bursts (3 minutes max) for intermittent service
Insulation / protection	Class F / IP X8, continuous duty S1
Liquid	Dirty water with suspended solids
Height	288 mm
Weight	5.4 kg
Available on request	Mechanical seal options; 10 m power cable; other voltages and 60 Hz

TOP-VORTEX range

Model	Code	Supply	Power	Flow	Head
TOP 1-VORTEX	2300142	Single Phase	0.25 kW / 0.33 HP	20–140 l/min	6.3–1.6 m
TOP 1-VORTEX/GM	2300172	Single Phase	0.25 kW / 0.33 HP	20–140 l/min	6.3–1.6 m
TOP 2-VORTEX	2300152	Single Phase	0.37 kW / 0.5 HP	20–155 l/min	7–2 m
TOP 3-VORTEX	2300162	Single Phase	0.55 kW / 0.75 HP	20–170 l/min	8.2–2.8 m

Head shown as the working range from minimum to maximum flow. Performance to Pedrollo 50 Hz data.

Frequently asked questions

What size solids will it pass?

Up to Ø 25 mm.

How long is the cable?

5 metres with a Schuko plug. A 10 m cable is available on request.
