Pedrollo RX
Pedrollo RXm5 auto 230v
In stock
- Established 1975
- Trusted by thousands of customers
Pedrollo RXm5 230v auto
The RX series pumps are suitable for use with clear water that does not contain abrasive particles.
As a result of the design solutions that have been adopted, such as the complete cooling of the motor and the shaft with double seal, these pumps are easy to use and reliable.
They are suitable for use in fixed installations and applications such as draining small flooded areas (rooms, cellars, garages) in the event of an emergency, for the disposal of waste water in the home (from dishwashers, washing machines) and for emptying drainage traps.
More about this product
Liquid type: clean water
Uses: domestic, civil
Applications: drainage, emptying tanks
typology: submersible
Family: submersible pumps
Performance Range:
- Flow rate up to 300 l/min (18,0 m³/h)
- Head up to 20 m
Application Limit:
- Temperature of the liquid to +40 °C
• 10 m maximum immersion depth
(with a sufficiently long power cable)
• Passage of suspended solids up to Ø 10 mm
• Suction level:
– 14 mm above ground level for RX 1-2-3
– 25 mm above ground level for RX 4-5
• Continuous service S1
RXm 1 5MT
RX 1 5MT
RXm 1 10MT
RX 1 10MT
RXm 2 5MT
RX 2 5MT
RXm 2 10MT
RX 2 10MT
RXm 3 5MT
RX 3 5MT
RXm 3 10MT
RX 3 10MT
RXm 4 10MT
RX 4 10MT
RXm 5 10MT
RX 5 10MT
-
data sheet PDFDownload
Standard delivery:
Standard delivery is free on most orders. Some items may incur a delivery charge depending on weight, size or value. Any applicable charge will be displayed at checkout.
Deliveries will typically be made between 7am and 6pm, Monday to Friday (excluding public holidays).
Next day delivery:
Next working day delivery is available for a £16.50 + VAT delivery charge.
Orders must be placed before 12 noon to qualify for next working day delivery. Orders placed after 12 noon on Thursday but before noon on Friday will be delivered the following Monday. Orders placed after 12 noon on Friday will be delivered on Tuesday.
Pallet/Large/Difficult items:
Some large, heavy or difficult to transport items may incur an additional delivery charge. Please contact us for a delivery quote before ordering.
Related products
Submersible sewage pump with a 40mm solids handling capacity. Cast iron construction suitable for pumping light domestic waste effluent septic tanks and large basements/cellars.
The Hippo 2 offers high performance at a low price, ideal for home and garden use this great submersible water pump will pump with 3,2mm…
Ebara Igrogo The Ebara Idrogo range is a 5″ submersible electric pump for wells and clean water pressure boosting. Common applications include garden watering, irrigation, general domestc…
The DAB Feka submersible pump has been designed for lifting dirty water. Explore the Feka and Fekafos range here at APS for quality pumps at…
The KP range of pumps from Grundfos is suitable for both temporary and permanent free-standing installation, as well as installation within a collecting tank. Easy-to-install,…
The Goliath Super is a robust sump pump made of stainless steel plate and fibre-reinforced plastic, resistance to corrosion. It also features a vortex impeller…
Frequently Asked Questions
Quick answers to common questions about the Pedrollo RXm5 auto 230v. For technical specifications, see the product details above; for sizing or installation advice, contact our team. If you have any other questions, we're happy to help.
What is a submersible pump?
A submersible pump is designed to operate fully submerged in the liquid it is moving. The motor is sealed inside the pump body and cooled by the surrounding water. Submersibles are used for drainage, sewage, septic tanks, deep wells and boreholes, and for raising water from sumps, cellars and floodwater. Many stocked at Anglian Pumping handle solids in suspension.
Can submersible pumps handle solids and sewage?
Yes – some submersibles are designed for clean water only, others handle solids up to 50 mm or full raw sewage. Anglian Pumping stocks ABS, BBC, Flygt and T-T Submersibles ranges that include vortex, single channel and grinder impellers for different solids handling requirements. Always match the pump to the maximum solid size and the type of effluent it will see.
When should I use a submersible pump instead of a surface pump?
Use a submersible when the water level is more than around 8 metres below the pump installation point – surface pumps cannot self-prime beyond that depth. Submersibles are also better when the liquid contains solids, when noise must be minimised, or when the pump needs to operate in confined spaces such as sumps and chambers where a surface pump would not fit.
