Wilo Hiperi
Wilo Hiperi 1-4 4186197
- Established 1975
- Trusted by thousands of customers
Wilo HiPeri 1-4 monobloc pump, Side channel pump, 230 V single-phase
Non self-priming cast iron peripheral pumps with brass impellers and low energy consumption, well-equipped for use in homes and buildings.
0.37 kW motor. Rp 1 connection.
More about this product
Overview
Non self-priming cast iron peripheral pumps with brass impellers and low energy consumption, well-equipped for use in homes and buildings.
The delivery head and pumping characteristics of these two affordable pumps are perfectly tailored to domestic needs.
Specification
| Model | Wilo HiPeri 1-4 |
|---|---|
| Part number | 4186197 |
| Series | HiPeri |
| Supply | 230 V single-phase, 50 Hz |
| Rated power P2 | 0.37 kW |
| Rated current | 2.5 A |
| Speed | 2900 rpm |
| Max. operating pressure | 7 bar |
| Fluid temperature | 5 °C to 60 °C |
| Ambient temperature | 5 °C to 40 °C |
| Protection class | X4 |
| Insulation class | F |
| Discharge port | Rp 1 |
Materials
| Pump housing | Grey cast iron |
|---|---|
| Impeller | Brass, CW617N |
| Shaft | Stainless steel |
| Shaft seal | BVPFF |
| Gasket material | NBR |
Dimensions and weight
| Pipe connection, suction | Rp 1 |
|---|---|
| Pipe connection, discharge | Rp 1 |
| Length × width × height | 207 × 118 × 145 mm |
| Net weight | 5 kg |
Features and equipment
Applications
- Domestic water supply
- Irrigation
- Rainwater utilisation
Frequently asked questions
Standard delivery:
Standard delivery is free on most orders. Some items may incur a delivery charge depending on weight, size or value. Any applicable charge will be displayed at checkout.
Deliveries will typically be made between 7am and 6pm, Monday to Friday (excluding public holidays).
Next day delivery:
Next working day delivery is available for a £16.50 + VAT delivery charge.
Orders must be placed before 12 noon to qualify for next working day delivery. Orders placed after 12 noon on Thursday but before noon on Friday will be delivered the following Monday. Orders placed after 12 noon on Friday will be delivered on Tuesday.
Pallet/Large/Difficult items:
Some large, heavy or difficult to transport items may incur an additional delivery charge. Please contact us for a delivery quote before ordering.
You may also need
The Pedrollo PKm 60 is a peripheral impeller pump for clean water. It has a 0.3 kW (0.4 HP) motor on a 230 V single-phase…
Frequently Asked Questions
Quick answers to common questions about the Wilo Hiperi 1-4 4186197. For technical specifications, see the product details above; for sizing or installation advice, contact our team. If you have any other questions, we're happy to help.
What is a peripheral pump?
A peripheral pump uses a small impeller and peripheral channel to generate relatively high pressure at modest flow rates.
What applications suit peripheral pumps?
They are commonly used for clean-water transfer and pressure applications where high head and comparatively low flow are required.
Can peripheral pumps handle abrasive liquids?
Generally they are intended for clean, non-abrasive liquids. Check the specific pump’s permitted liquid properties before use.
What types of Wilo pumps are available?
Wilo manufactures circulators and other pumping solutions for heating, cooling, water supply and building services applications.
What is a Wilo circulator pump used for?
A Wilo circulator moves water around a heating or cooling circuit to maintain the required flow through the system.
How do I select a replacement Wilo pump?
Match the existing model or confirm head, flow, installation length, connections, voltage and control requirements before ordering.
