Grundfos Magna 3 D F
Magna 3 D 40-60 F* 97924462
In stock
- Established 1975
- Trusted by thousands of customers
The Grundfos MAGNA3 D 40-60 F is a high-efficiency, twin-head circulator pump designed for a variety of applications, including heating, cooling, and commercial systems. Its twin-head design ensures double the performance and reduced downtime, as the two pumps communicate wirelessly to optimize operation.
Key Features:
- Energy Efficiency: The MAGNA3 series boasts an Energy Efficiency Index (EEI) that complies with the EuP 2015 requirements, achieving energy savings of up to 75% compared to typical installed circulators.
- AUTOADAPT Function: This feature allows the pump to analyze system demands and automatically adjust its operation to find the optimal setting, ensuring efficient performance.
- Built-in Heat Energy Meter: By installing a separate temperature sensor in the return pipe, the MAGNA3 can monitor and log energy consumption, helping users identify potential inefficiencies in the system.
- FLOWADAPT and FLOWLIMIT: These functions enable the pump to limit maximum flow, eliminating the need for a balancing valve on the main flow and return pipe, and combine the benefits of flow limitation with automatic adjustment to system demands.
Technical Specifications:
- Pipe work connections : 40mm or 1 1/2″ flanged
- Maximum Head: 6 meters
- Voltage: 240V single-phase
- Material: Cast iron
The MAGNA3 D 40-60 F is suitable for various applications, including:
- Heating systems
- Air conditioning and cooling systems
- Domestic water systems
- Ground-source heat pump systems
- Solar heating systems
Its advanced features and adaptability make it an ideal choice for engineers and specifiers aiming to design high-performance heating and cooling systems
More about this product
This unique feature benefits both:
- Consulting engineers, who can rest assured that the pumps meet the necessary performance standards without being overly big or expensive.
- Installation specialists, who know that little to no follow-up manual adjustments will be necessary, with the pump able to achieve the optimum performance standards automatically.
The MAGNA range offers unprecedented reliability, and an incredibly easy-to-use installation connection (simply plug-and-pump). A range of quality features are put in place to achieve the best possible results:
- The pumps contain both threaded and flange connections in order to allow for easy installations in both new and already existing systems.
- The rotor used in the models makes use of permanent-magnet technology which is designed to help increase energy savings at a higher level than other speed-controlled circulator pumps can manage.
- Sophisticated electronics within the unit mean it remains cool and can continually operate without any issues.
- An easy-to-use interface based around simplicity. The operating panel shows only the most essential performance parameters, meaning that it’s easier to read than others in the industry. Pump performance, meanwhile, can be adjusted with a simple button press.
- The team behind the MAGNA conducted a great deal of research and 3D testing prior to release, ensuring that the final model’s pump housing and impeller are perfectly optimised to fit together. This helps to conserve the amount of energy used.
The MAGNA series can be used to suit a range of different hot water systems, including central heating, mains pumps, mixing loops, heating and air-conditioning. It can also be installed into solar-heating systems, an external signal enabling the pump to operate according to the maximum curve.
The MAGNA 3 D is a twin head version of the popular main model.
-
sales Sheet PDFDownload
-
data sheet PDFDownload
Standard delivery:
Standard delivery is free for all orders except for some low cost/low margin items where standard delivery is £6.75. Some difficult to transport goods also have a varying carriage charge applied.
Please contact us for the estimated standard delivery times of the products that we have in stock, either by calling 01473 719950, or by dropping us an email at info@anglianpumping.com.
Deliveries will typically be made between 7am and 6pm, Monday to Friday (excluding public holidays).
Next day delivery:
Next working day delivery is available for a £15.00 + vat delivery charge.
Orders must be placed before 12 noon to qualify for next working day delivery. Orders placed after 12 noon on Thursday but before noon on Friday will be delivered the following Monday. Orders placed after 12 noon on Friday will be delivered on Tuesday.
