Calpeda NCS3 Series Circulator Pumps
CALPEDA NCS3 25-50/130 ENERGY EFFICIENT CIRCULATOR PUMP 240V
- Established 1975
- Trusted by thousands of customers
Calpeda NCS3 25-50/130 is a Calpeda 3-speed circulator with a bronze pump casing for domestic hot water circulation. Maximum head is 5 m and maximum power input 81 W.
Suction and delivery ports are the same size and on the same axis (in-line), and it comes standard with brass unions.
More about this product
Calpeda NCS3 25-50/130 overview
Calpeda NCS3 25-50/130 is a Calpeda 3-speed circulator with a bronze pump casing for domestic hot water circulation. Maximum head is 5 m and maximum power input 81 W.
Suction and delivery ports are the same size and on the same axis (in-line), and it comes standard with brass unions.
Specifications
| Model | Calpeda NCS3 25-50/130 |
|---|---|
| Motor | 2-pole induction motor, single-phase 230 V, 50 Hz, three speeds |
| Max. power input | 81 W (speed 3) |
| Max. head | 5 m (0.5 bar) |
| Ports | G 1½ (ISO 228), in-line, 130 mm port-to-port |
| Unions | Brass, supplied as standard |
| Liquid temperature | +5 °C to +65 °C |
| Max. working pressure | 10 bar |
| Sound pressure | ≤ 45 dB(A) |
| Weight | 2.6 kg |
Materials
| Component | Material |
|---|---|
| Pump casing | Bronze |
| Impeller | Composite PES |
| Shaft | Ceramic |
| Ball and thrust bearings | Ceramic |
| Gasket | EPDM |
Applications
- Domestic hot water circulation systems
Frequently asked questions
Technical data: Calpeda NCS3 data sheet.
-
Data Sheet PDFDownload
Standard delivery:
Standard delivery is free on most orders. Some items may incur a delivery charge depending on weight, size or value. Any applicable charge will be displayed at checkout.
Deliveries will typically be made between 7am and 6pm, Monday to Friday (excluding public holidays).
Next day delivery:
Next working day delivery is available for a £16.50 + VAT delivery charge.
Orders must be placed before 12 noon to qualify for next working day delivery. Orders placed after 12 noon on Thursday but before noon on Friday will be delivered the following Monday. Orders placed after 12 noon on Friday will be delivered on Tuesday.
Pallet/Large/Difficult items:
Some large, heavy or difficult to transport items may incur an additional delivery charge. Please contact us for a delivery quote before ordering.
Related products
The Grundfos TP single stage bronze steel pump complete with 4 pole electric motor. Single stage, close-coupled, volute pump with in-line suction and discharge ports of idenctical…
The Grundfos MAGNA3 F N Stainless Steel Flanged Circulator Pumps range covers 25 single-head, stainless steel, flanged circulators from DN32 to DN65, with maximum heads…
The Grundfos MAGNA3 D Twin-Head Screwed Circulator Pumps range covers 4 twin-head, cast iron, screwed (union) circulators from 32 to 32, with maximum heads from…
The Lowara Ecocirc XLplus system is designed to circulate liquids in heating systems with variable flows where it is desirable to enhance the settings of the pump duty…
The Grundfos MAGNA3 N Stainless Steel Screwed Circulator Pumps range covers 9 single-head, stainless steel, screwed (union) circulators from 25 to 32, with maximum heads…
The Grundfos TP single stage cast iron pump complete with 4 pole 230v electric motor. Single stage, close-coupled, volute pump with in-line suction and discharge ports of…
Frequently Asked Questions
Quick answers to common questions about the CALPEDA NCS3 25-50/130 ENERGY EFFICIENT CIRCULATOR PUMP 240V. For technical specifications, see the product details above; for sizing or installation advice, contact our team. If you have any other questions, we're happy to help.
What types of Calpeda pumps can I explore?
Calpeda produces pumps for water supply, pressure boosting, drainage and circulation. Choose a model according to the required flow, head and liquid.
Are Calpeda pumps suitable for commercial installations?
Yes. Calpeda offers pump ranges for domestic, commercial and industrial duties; suitability depends on the individual model and duty point.
How do I choose a replacement Calpeda pump?
Check the existing pump model, supply voltage, connection dimensions, flow rate and required head before selecting a replacement.
