Name: Lowara LNTEK 65-340/55/204CS4 In-Line Pump 1019LD2L0
SKU: LNTEK 65-340/55/204CS4
Price: 9840.96 GBP
Availability: InStock

Lowara LNTEK 65-340/55/204CS4 In-Line Pump 1019LD2L0

Any questions? Message us on WhatsApp

Established 1975
Trusted by thousands of customers

e-LNT in-line pump · Single-stage in-line · size 65-340 · DN 65 flanged · cast iron · in-line twin · Lowara part no. 1019LD2L0

KEY SPECIFICATIONS

Typee-LNT in-line

Pump size65-340

Motor5.5 kW

ConnectionsDN 65

ConfigurationIn-line twin

DutyStandard duty

Lowara part no. 1019LD2L0

↓ Data sheet (PDF)

Full Description

More about this product

Full Description

The Lowara LNTEK 65-340/55/204CS4 is a single-stage in-line centrifugal pump from the e-LNT range, a close-coupled in-line twin unit with two pumps. The twin-head design puts two pumps in one unit for duty/standby or parallel running. Built for high flow rates in water supply, HVAC, cooling and industrial transfer, with a cast-iron casing, flanged connections and back pull-out servicing.

SKU: LNTEK 65-340/55/204CS4 · Lowara part no. 1019LD2L0

Why this pump

✓ Single-stage in-line✓ In-line twin✓ Cast iron casing✓ Flanged EN 1092

Specification

Type	Single-stage in-line centrifugal (e-LNT in-line, close-coupled twin)
Lowara part number	1019LD2L0
Pump size	65-340
Motor power	5.5 kW
Discharge connection	DN 65, flanged (EN 1092)
Configuration	A close-coupled in-line twin unit with two pumps
Duty type	Standard duty
Casing material	Cast iron EN-GJL-250 (bronze / stainless options – see data sheet)
Max liquid temperature	Up to +120 °C (standard seal)
Mechanical seal	To EN 12756 (ISO 3069)
Motor	IE3 high-efficiency, ErP compliant

↓ Download data sheet (PDF)

Built for

Water supply & boosting

High-flow pressure boosting and transfer for buildings, networks and tanks.

HVAC

Heating, chilled-water and condenser-water circulation in commercial buildings.

Cooling & process

Cooling circuits, process transfer and general industrial duties.

Irrigation

Bulk pressurised supply to agricultural and landscape irrigation systems.

FAQs

What does the size code mean?

The first number is the discharge bore (e.g. 32 = DN32) and the second is the nominal impeller diameter in mm.

What’s the difference between e-LNE and e-LNT?

Both are close-coupled in-line pumps. e-LNE is a single pump; e-LNT is the in-line twin version — two pumps in one in-line unit for duty/standby or higher combined flow.

Can you confirm the duty point?

Send us your flow and head and we’ll confirm the exact model, impeller trim and motor.
