Name: Lowara 33SV8/1AG185T/E Vertical Multistage Pump 101680C21
SKU: 33SV8/1AG185T/E
Price: 8523.48 GBP
Availability: InStock

Lowara 33SV8/1AG185T/E Vertical Multistage Pump 101680C21

Established 1975
Trusted by thousands of customers

Vertical multistage pump · 33 m³/h · 18.5 kW 3-phase · stainless steel · Lowara part no. 101680C21

KEY SPECIFICATIONS

Flow class33 m³/h

Motor18.5 kW

Supply3-phase

Wetted materialStainless steel

Max temperature120 °C

Lowara part no. 101680C21

↓ Data sheet (PDF)

Full Description

More about this product

Full Description

The Lowara 33SV8/1AG185T/E is a vertical multistage centrifugal pump from the e-SV series with a nominal duty around 33 m³/h. All parts in contact with the pumped liquid are stainless steel, with stainless connections. It handles clean water free of suspended solids for pressure boosting, water treatment, washing and HVAC duties.

SKU: 33SV8/1AG185T/E · Lowara part no. 101680C21

Why this pump

✓ Stainless steel✓ ErP / IE3 motor✓ EN 12756 seal

Specification

Pump type	Vertical multistage centrifugal (non-self-priming)
Lowara part number	101680C21
Nominal flow class	33 m³/h
Motor power	18.5 kW
Electrical supply	3-phase
Wetted materials	stainless steel
Max liquid temperature	120 °C
Min liquid temperature	−30 °C
Mechanical seal	Balanced, to EN 12756 (ISO 3069)
Efficiency	IE3 motor, ErP 2009/125/EC compliant

↓ Download data sheet (PDF)

Built for

Water supply & pressure boosting

Boosting for buildings, hotels and residential complexes; booster sets and water-network supply.

Water treatment

Reverse osmosis, ultrafiltration, softening and demineralisation feed duties.

Light industry & washing

Washing and degreasing lines, vehicle wash, commercial washers and process transfer.

HVAC & irrigation

Heating and air-conditioning circuits, and sprinkler/drip irrigation needing steady high head.

FAQs

What does the model code mean?

The leading number is the nominal flow in m³/h, the next pair is the number of stages, and the letter (F/T/R/N/V/P/C/K) sets the connection type and 304/316 material.

Can you size it to my duty?

Send us the flow and head you need and we’ll confirm the exact stage count and motor.

Is it suitable for drinking water?

The F, T, R and N versions are WRAS and ACS certified for potable water.
