Calpeda C Centrifugal Pump
Calpeda C 41/A Cast Iron Centrifugal Pump (3 Phase) 70600112000
- Established 1975
- Trusted by thousands of customers
Calpeda C 41/A is a Calpeda close-coupled centrifugal pump with open impeller, part number 70600112000. It delivers up to 250 l/min (15 m³/h) and a maximum head of 22.4 m (2.2 bar), driven by a 1.1 kW motor (three-phase 230/400 V 50 Hz).
The Calpeda C is a close-coupled centrifugal pump with an open impeller (free-flow vortex impeller on the C 16/1), built to handle moderately dirty liquids and emulsions. The pump casing and lantern bracket are cast iron and the pump is supplied fully painted.
More about this product
Calpeda C 41/A overview
Calpeda C 41/A is a Calpeda close-coupled centrifugal pump with open impeller, part number 70600112000. It delivers up to 250 l/min (15 m³/h) and a maximum head of 22.4 m (2.2 bar), driven by a 1.1 kW motor (three-phase 230/400 V 50 Hz).
The Calpeda C is a close-coupled centrifugal pump with an open impeller (free-flow vortex impeller on the C 16/1), built to handle moderately dirty liquids and emulsions. The pump casing and lantern bracket are cast iron and the pump is supplied fully painted.
Specifications
| Model | Calpeda C 41/A |
|---|---|
| Calpeda part number | 70600112000 |
| Motor power (P2) | 1.1 kW (1.5 HP) |
| Supply | Three-phase 230/400 V 50 Hz |
| Rated current | 4.6 A at 230 V / 2.7 A at 400 V |
| Max. flow | 250 l/min (15 m³/h) at 15.5 m |
| Max. head | 22.4 m (2.2 bar) |
| Head at shut-off (zero flow) | 22 m (2.2 bar) |
| Connections | G 1½ suction and delivery |
| Liquid temperature | -10 °C to +90 °C |
| Ambient temperature | up to 40 °C |
| Total suction lift | up to 8 m |
| Max. working pressure | 6 bar |
| Max. solids size | 4 mm |
| Duty | Continuous |
Performance
Total head at each flow, from the Calpeda C 50 Hz data sheet (approx. rated speed, clean cold water).
| Flow (l/min) | Flow (m³/h) | Head (m) | Pressure (bar) |
|---|---|---|---|
| 0 (shut-off) | 0 | 22 | 2.2 |
| 80 | 4.8 | 22.4 | 2.2 |
| 100 | 6 | 22.3 | 2.2 |
| 110 | 6.6 | 22.2 | 2.2 |
| 140 | 8.4 | 21.5 | 2.1 |
| 160 | 9.6 | 21 | 2.1 |
| 180 | 10.8 | 20.5 | 2 |
| 200 | 12 | 19.5 | 1.9 |
| 220 | 13.2 | 18 | 1.8 |
| 250 | 15 | 15.5 | 1.5 |
Construction and features
- Close-coupled centrifugal pump with open impeller (free-flow impeller on C 16/1)
- Cast iron pump casing and lantern bracket, brass impeller
- Threaded ports
- 2-pole induction motor, 50 Hz, approx. 2900 rpm, insulation class F, IP54
- IE3 efficiency class three-phase motors (IE2 up to 0.65 kW)
- Motor suitable for use with a frequency converter from 1.1 kW
Materials
| Component | Material |
|---|---|
| Pump casing | Cast iron GJL 200 EN 1561 |
| Lantern bracket | Cast iron GJL 200 EN 1561 |
| Impeller | Brass CW617N EN 12167 |
| Shaft | Stainless steel AISI 430F |
| Mechanical seal | Carbon / ceramic / NBR |
Applications
- Moderately dirty liquids or emulsions, with solids up to 4 mm
- Industry and agriculture
Frequently asked questions
Technical data: Calpeda C data sheet, 50 Hz. Performance tolerances to UNI EN ISO 9906:2012.
